IPCSD416X

4MP, 16x, WDR, LIGHTHUNTER, PTZ DOME

Want to buy this product?
Find A Dealer

Key Features

  • Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
  • Light Hunter illumination technology ensures ultra-high quality with 4MP, 2688 x 1520 Resolution, with Super-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage
  • Ultra-Powerful, Smart IR LED Lights for 0 Lux Nighttime Operation up to 328 Feet
  • 5.5 ~ 88mm, 16x Optical motorized zoom and focus lens
  • TRUE Day/Night and WDR functionality for all Lighting Conditions
  • Two-way Audio, Backlight Compensation and 3D DNR (Digital Noise Reduction)
  • High Speed up to 240°/sec and up to 1024 Preset Positions
  • Dual Video Streams; ONVIF Profile Series Compliant; with Motion Detection
  • IP67 / IK10 Weather / Vandal Resistant Housing and PoE & 12VDC Power Options
  • Wall, Pole & Corner Mounts Available
  • Built-in Micro-SD Card Slot enables local storage up to 512GB
  • Supported by Uniview tec Guard Station Software and Guard Live or Guard Viewer Mobile App’s for iPhone and Android Device

SKU: IPCSD416X Categories: ,
Camera
Sensor 1/2.9” 4MP, CMOS
Minimum illumination Color: 0.005 lux (F1.78, AGC ON); 0 lux with IR on
True Day / Night IR-cut filter with auto switch (ICR)
Shutter Auto / Manual, 1 ~ 1/100000s
WDR 120dB
S/N >56dB
Lens
Lens 5.5 ~ 88mm
Optical / Digital Zoom 16x
Iris F1.78-F3.73
Field of View (H) 50.85°~3.47°
Field of View (V) 29.94°~1.95°
Field of View (D) 62.55°~4.09°
DORI
DORI Distance
Lens (mm)

5.5

88

 Detect (m)

127.6m (418.6 ft)

2048m (6720.5 ft)

 Observe (m)

51.1m (167.4 ft)

819.4m (2688.2 ft)

 Recognize (m)

25.5m (83.7 ft)

409.7m (1344.1 ft)

Identify (m)

12.8 (41.9 ft)

204.8 (672 ft)
Illuminator
IR Range Up to 100m (328ft) IR range
Wavelength 850nm
IR On/Off Control Auto/Manual
Video
Video Compression H.265, H.264, MJPEG
Frame Rate Main: 4MP (2688 x 1520), Max 30fps
Sub: 720P (1280 x 720), Max 30fps
Video Bit Rate 128 Kbps~16 Mbps
U-code / ROI Support
OSD Up to 4 OSDs
Privacy Mask 24 areas, up to 4 areas per scene
Video Stream Dual streams
White Balance Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
Digital Noise Reduction 2D / 3D DNR
Smart IR Support
Flip Normal / Vertical / Horizontal / 180°
HLC Support
BLC Support
Defog Digital Defog
Intelligence
Smart intrusion prevention Support false alarm filtering: Cross Line detection and Intrusion detection
Events
Basic Detection Motion detection, Audio detection, Tampering Alarm
Auto Tracking Support
General Function Watermark, IP Address Filtering, Alarm input, Access Policy, ARP Protection, RTSP Authentication,User Authentication
Audio
Audio Compression G.711U, G.711A
Audio Bitrate 128 Kbps
Two-way audio Support
Suppression Support
Sampling Rate 16kHZ
Storage
Edge Storage Micro SD, up to 512GB
Network Storage ANR, NAS(NFS)
Network
Protocols IPv4; IPv6; IGMP; RTP; ICMP; ARP; TCP; UDP; DHCP; PPPoE; RTSP; RTCP; RTMP; DNS; DDNS; NTP; FTP; UPnP; HTTP; HTTPS; 802.1x; SNMP; QoS; SSL/TLS
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API,SDK
User/Host Up to 32 users. 3 user levels: administrator, common user and operator
Security Password Protection; Strong Password; HTTPS Encryption; Export Operation Logs; Basic and Digest Authentication for RTSP; Digest Authentication for HTTP; TLS 1.2; WSSE and Digest Authentication for ONVIF
Client Guard Station, Guard Viewer, Guard Live
Web Browser Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
Pan & Tilt
Pan Range 360° (endless)
Pan Speed 0.1°/s ~ 240°/s
Tilt Range –5° ~ 90° (auto flip)
Tilt Speed 0.1°/s ~ 120°/s
Number of Presets 1024
Preset Patrol 16 patrols, up to 64 presets for each patrol
Route Patrol 16 patrols, up to 32 actions for each patrol
Recorded Patrol 16 patrols, up to 128 actions for each patrol
Patrol Stay Time 15s~1800s
Home Position Support
Interface
Audio I/O 1 / 1
Alarm I/O 2 / 1
Serial Port 1 x RS485
Network 1 x RJ45 10M/100M Base-TX Ethernet
General
Power DC 12V (±10%, 3A), PoE+ (IEEE 802.3at); Power consumption: Max 23W
Power Interface Ø 5.5mm coaxial power plug
Dimensions (Ø × H) Ø167 x 181mm (Ø6.6” x 7.1”)
Weight 2.3Kg (5.07lb)
Environment 40°C ~ 70°C (-40°F ~ 158°F), Humidity: ≤95% RH (non-condensing)
Surge Protection 6KV
Conformity Certifications IP66, IK10, CE, FCC
TR-CE45-IN TR-CE45-IN

Pendant Mount Pipe

TR-JB12-IN TR-JB12-IN

JUNCTION BOX

TR-WE45-B-IN TR-WE45-B-IN

Parapet Mount
