IPB4K180X
IPB4K180X

4K, 180° PANORAMIC LENS, INTELLIGENT BULLET

Want to buy this product?
Find A Dealer

Key Features

  • Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
  • Exceptional Video Quality with 4K (8MP), 3840 x 2160 Resolution
  • Super-Efficient H.265 Video Compression for Drastically Reduced Bandwidth and Storage Requirements
  • Powerful, Smart IR LED Lights for 0Lux Night Time Operation up to 66 Feet
  • Panoramic 1.68mm, 180° wide angle lens; ONVIF Profile S Compliant
  • TRUE Day/Night and WDR functionality for all Lighting Conditions
  • Triple Video Streams; Backlight Compensation, 3D DNR, Built-in Microphone
  • Built-in Micro-SD Card Slot enables local storage up to 512GB
  • Intelligent perimeter protection such as cross line and intrusion, with smart intrusion prevention technology for significantly reduced false alarms when focusing on humans and motor vehicles
  • 3-Way Axis, IP67 Weather Resistant; PoE & 12VDC Power Options
  • Supported by uniview tec Guard Station Software and Guard Viewer Mobile App’s for iPhone and Android Device

SKU: IPB4K180X Categories: ,
Camera
Sensor 1/2.7''CMOS
Minimum illumination Color: 0.01 lux (F2.0, AGC ON); 0 Lux with IR
Day / Night IR-cut filter with auto switch (ICR)
Shutter Auto / Manual, 1 ~ 1/100000s
Adjustment angle (3-way Axis) Pan: 0° ~ 360°; Tilt: 0° ~ 90°; Rotate: 0° ~ 360°
WDR 120dB
S/N >52dB
Lens
Lens 1.68mm
Iris F2.0
Field of View (H) 180°
Field of View (V) 100°
Field of View (O) 180°
DORI
DORI Distance Detect Observe Recognize Identify
37.8m (124ft) 15.1m (49.6ft) 7.6m (24.8ft) 3.8m (12.4ft)
Illuminator
IR Illumination Distance Up to 20m (66ft) IR range
IR On / Off Control Auto / Manual
Wavelength 850nm
Video
Video Compression Ultra 265, H.265, H.264, MJPEG
H.264 code profile Baseline profile, Main profile, High profile
Frame Rate Main Stream: 8MP (3840 x 2160), Max 30fps; 5MP (3072 x 1728), Max 30fps; 4MP (2560 x 1440), Max 30fps; 1080P (1920 x 1080), Max 30fps;
Sub Stream: 720P (1280 x 720), Max 30fps; D1 (720 x 576), Max 30fps; 640 x 360, Max 30fps; 2CIF(704 x 288), Max 30fps;
CIF(352 x 288), Max 30fps;
Third Stream: D1 (720 x 576), Max 30fps; 640 x 360,Max 30fps; 2CIF(704 x 288), Max 30fps; CIF(352 x 288), Max 30fps;
Video Bit Rate 128 Kbps~16 Mbps
U-code Supported
OSD Up to 8 OSDs
Privacy Mask Up to 4 areas
ROI Up to 8 areas
Video Stream Triple streams
Auto Scene Match (ASM) Support (Only WDR)
White Balance Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2
Digital Noise Reduction 2D / 3D DNR
Smart Illumination Supported
Flip Normal; Flip Vertical; Flip Horizontal; 180°
Dewarping Supported
HLC Supported
BLC Supported
Defog Digital Defog
Low Illumination Characteristics Low-light
Intelligent Analytics
Smart intrusion prevention Support false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection
Events
Basic Detection Motion detection, Ultra motion detection, Tampering alarm, Audio detection
General Function Watermark; IP Address Filtering; Alarm input; Alarm output; Access Policy; ARP Protection; RTSP Authentication; User Authentication; HTTP Authentication
Audio
Audio Compression G.711U;G.711A
Audio Bitrate 64 Kbps
Suppression Support
Sampling Rate 8KHZ
Storage
Edge Storage Micro SD, up to 512GB
Network Storage ANR
Network
Protocols IIPv4; IPv6; IGMP; ICMP; ARP; TCP; UDP; DHCP; PPPoE; RTP; RTSP; RTCP; RTMP; DNS; DDNS; NTP; FTP; UPnP; HTTP; HTTPS; SMTP; 802.1x; SNMP; QoS
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API
User/Host Up to 32 users. 3 user levels: administrator, common user and operator
Security Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Client Guard Station, Guard Viewer
Web Browser Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above;
Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
Interface
Built-in Microphone Supported
Network 1 * RJ45 10M/100M Base-TX Ethernet
Conformity Certifications
EMC CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035), FCC (FCC 47 CFR part15 B)
Safety CE LVD (EN 62368-1); UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
Environment CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)
Protection IP67 (IEC 60529)
General
Power DC 12V ±25%, PoE (IEEE 802.3af); Power consumption: Max 5.5W
Power Interface Ø 5.5mm coaxial power plug
Dimensions (Ø × H) 198× 71 × 71mm (7.8 × 2.8 × 2.8”)
Weight 0.42kg (0.93lb)
Working Environment -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Surge Protection 4KV
Reset Button Support
TR-JB05-B-IN TR-JB05-B-IN

Junction Box

Waterproof Plastic Grommet TR-A01-IN

Waterproof Plastic Grommet

Pole Mount 127 x 136 x 62.5mm (5 x 5.35 x 2.46”) TR-UP06-C-IN

Pole Mount

Pole Mount 127 x 136 x 62.5mm (5 x 5.35 x 2.46”) TR-UC08-C

Corner Mount
